PER50TR

PER 50 TR

Description & Applications

Peripheral positive displacement pumps with frontal pumps for small household systems and simple industrial applications; characterized by a considerable ratio between performance and required output.

Main Features:

• Pump has an epoxy electro coating treatment
• Flow rate up to 35 l/min
• Head up to 37 m
• Max water temperature 50 ºc
• Ambient temperature up to 40 ºc

Component Construction

• Pump body             Cast iron G20
• Pump bracket        Cast iron G20
• Impeller                  Brass H59
• Pump shaft            Stainless steel AISI 304
• Mechanical seal    Ceramic / Graphite

Motor

• Two-pole induction motor (n=2900 r.p.m)
• External cooling
• Insulation class F
• Protection degree IP44
• Single phase 220V/50Hz
• Thermal protection
• Continuous service S1
